Size Range

¼” to 48” (DN 6 to DN 1200)

Material Options

Stainless Steel (SS 304, SS 316, SS 316L), Carbon Steel (ASTM A216 WCB), Duplex Steel, Alloy Steel (ASTM A182 F22), Cast Iron (ASTM A126 Class B), Bronze, Brass (IS 319 Type 1, DZR Brass)

Pressure Rating

Class 150 to Class 2500, PN10 to PN420, Hydraulic Valves up to 700 bar (10,000 PSI).

Working Temperature

-196°C to 450°C (Cryogenic to high-temperature applications)

Seat Material

PTFE, RPTFE, CPTFE, NYLON  PEEK, Metal-to-Metal

End Connections

Flanged (RF, FF), Screwed (BSP, NPT), Socket Weld (SW), Butt Weld (BW), Tri-Clamp. ASME B16.5 (Flanges), ASME B16.11 (SW), ASME B1.20.1 (Threaded).

Manufacturing Standards

API 6D, API 607 (Fire-Safe), ASME B16.34, ISO 5211, BS 5351, EN 13709, DIN 3357, DIN EN 1092-1 (Flanges), DIN 3230 (Testing). JIS B2002.

Media Compatibility

Water, Oil, Gas, Chemicals, Steam, Slurry, Hydraulic Fluids, Acidic and Alkaline Solutions.

Actuation Options

Manual (Lever/Gear), Pneumatic, Electric, Hydraulic.

Design Standards

Fire Safe (API 607, ISO 10497), Anti-Static, Blowout-Proof Stem Design. API 6D, BS EN ISO 17292, ASME B16.34.

Dimensions

ASME B16.10, BS 5351, DIN 3202.

Face-to-Face

ASME B16.10.

Leakage Class

ANSI Class VI (Soft Seat), Class IV (Metal Seat)

Testing

API 598, ISO 5208.
