HMISTO532

Price on Request

Min Order Qty 1

Product not available

Touch panel screen 3''4 Monochrome Ethernet W/P/R

Description
Business Information

Main
range of product	Harmony STO & STU
product or component type	Touch panel screen
software designation	Vijeo Designer
operating system	Harmony
processor name	CPU RISC

Complementary
display size	3.4 inch
display type	Backlit monochrome STN LCD
background colour	White, pink and red
display resolution	200 x 80 pixels
touch panel	Analogue
backlight lifespan	10000 hours with red 50000 hours with pink 50000 hours with white
brightness	8 levels
contrast	16 levels via touch panel
character font	Korean ASCII Japanese (ANK, Kanji) Chinese (simplified Chinese) Taiwanese (traditional Chinese)
[Us] rated supply voltage	24 V DC +/- 20 %
inrush current	30 A
local signalling	1 LED (green)normal operation:
power consumption in W	5 W
number of pages	Limited by internal memory capacity
processor frequency	333 MHz
port Ethernet	10/100BASE-TX
memory description	Application memory 16 MB Back up of data 128 kB
integrated connection type	1 USB 2.0 type mini B 1 USB 2.0 type A power supply - removable screw terminal block 1 Ethernet TCP/IP - 1 RJ45
supply	External source
realtime clock	Access to the PLC real-time clock
downloadable protocols	XWAY TCP/IP Modbus TCP/IP Third party protocols
fixing mode	By 2 spring clips, mounting on 1.6...5 mm thick panel
enclosure material	PPT
marking	CE

Environment
immunity to microbreaks	3 ms
standards	UL 508 FCC Class A IEC 61000-6-2 UL 1604 EN 61131-2
product certifications	UL Class 1 Division 2 T4A C-Tick CULus CE UL Class 1 Division 2 T5
ambient air temperature for operation	0…50 °C
ambient air temperature for storage	-20…60 °C
relative humidity	0…90 % without condensation
operating altitude	<= 2000 m
IP degree of protection	IP20 (rear panel) conforming to IEC 60529 IP65 (front panel) conforming to IEC 60529
NEMA degree of protection	NEMA 4X front panel (indoor use)
shock resistance	15 gn for 11 ms conforming to IEC 60068-2-27
vibration resistance	+/- 3.5 mm (f = 5…9 Hz) conforming to IEC 60068-2-6 1 gn (f = 9…150 Hz) conforming to IEC 60068-2-6
electromagnetic compatibility	Resistance to radiated electromagnetic fields - test level: 10 V/m conforming to IEC 61000-4-3

Packing Units
Package 1 Weight	0.386 kg
Package 1 Height	85.000 mm
Package 1 width	135.000 mm
Package 1 Length	185.000 mm

Offer Sustainability
REACh free of SVHC	Yes
EU RoHS Directive	Pro-active compliance (Product out of EU RoHS legal scope) EU RoHS Declaration
Mercury free	Yes
RoHS exemption information	Yes
China RoHS Regulation	China RoHS declaration
WEEE	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins

Contractual warranty
Warranty	18 months
