ITC-HSN: 8481
Min Order Qty 1
Accept Small Orders
Product not available
Parameter Specification
Size Range ½” (15mm) to 24” (600mm)
Body Material Cast Iron, Ductile Iron, WCB, LCB, CF8, CF8M, CF3M, Duplex Steel, Super Duplex, Alloy 20, Monel, Hastelloy
Screen Material SS304, SS316, SS316L, Duplex SS, Monel, Hastelloy
Working Temperature -29°C to 425°C depending on material
n
Contact us for
Pressure Ratings ANSI / ASME Class 150, 300, 600, 900, 1500 / PN10, PN16, PN25, PN40, PN100, PN250
End Connections Flanged (ASME B16.5), Screwed (BSP/NPT), Socket Weld (ASME B16.11), Butt Weld (ASME B16.9), ASME B1.20.1 (Threaded), EN 1092-1, DIN 2633
Design Standards ASME B31.1, ASME B31.3, EN 13445, DIN 3356, ISO 9001:2015
Testing Standards API 598, EN 12266-1, ISO 5208
Screen Perforations 0.5mm to 6mm or customized
Mesh Options 20 Mesh to 400 Mesh depending on process requirement
Manufacturing Certification ISO 9001:2015, CE Certification
Face-to-Face ASME B16.10, EN 558, DIN 3202
Inspection ISO 9001:2015, EN 10204 3.1 / 3.2 Material Certification, CE Certificatio
| Established in: | 2021 |
| Bussiness Type: | Sole Proprietorship |
| Bussiness Type: | Manufacturer |
| MSME: | Yes |
| Countries exporting to: | Canada, Egypt, Ghana, Mexico, Nigeria, Qatar, Saudi Arabia, Spain, United Arab Emirates, United States |
| Export Turnover (3 years): | US$1,000,000 - US$5,000,000 |
| Certifications: | Chamber of Commerce |
| Countries would like to export to: | Algeria, Argentina, Australia, Bahrain, Bangladesh, Belgium, Bhutan, Brazil, Canada, China |
| No of employees: | 31-50 |
