Specifications

• Material : WCB / CI / DI / CF8 / CF8M

• Size range : 40MM To 800MM
• Seat : NBR / EPDM / Viton

• Pressure : PN 10 / PN 16

• Temperature : Upto 85°C & Upto 150°C

• Media : Water

• Ends : Flanged


Features

• Automatic Water Level Control : Maintains preset water level in overhead tanks and reservoirs without manual intervention.

• Hydraulic Operation : Works on hydraulic principle, requires no external power source.

• Overflow Protection : Automatically closes at full level to prevent overflow and water wastage.

• Floatless Design : Eliminates mechanical floats, reducing wear and maintenance.

• Durable Construction : Built with high-quality corrosion-resistant materials for long service life.

• Smooth Flow Regulation : Ensures stable performance with minimal pressure loss.

• Low Maintenance : Simple design minimizes servicing and operational costs.

• Wide Application Use : Ideal for municipal water supply, industrial plants, irrigation systems, and reservoirs.

• Reliable Performance : Engineered by 4Matic Valves with precision for safety and efficiency.

• Versatile Sizes Available : Suitable for small to large capacity tanks and diverse project requirements.
